Technical features

Outer dimensions

163cm x 80cm
Mattress platform extension 0cm
Recommended mattress size 132cm x 67.5cm
Max. mattress height N/A
Bed height 85.5 – 117.0cm by 10degrees
Maximum backrest angle 78°
Maximum thigh rest angle
Trendelenburg/Anti-Trendelenburg position +10°/-10°
Ergoframe N/A
Heightof side rails (above mattress platform) 80cm
Weight (basic equipment) 85kg
Safe working load 75kg

Height adjustment – mechanical ratchet

TR/ATR tilt adjustment – mechanical ratchet

Backrest adjustment – mechanical

Steel side rails with gap < 60 mm

2-section mattress platform

4 castors ⌀125 mm individually braked

Steel with gap < 60 mm
